Vent-A-Hood TH248SLE 48-Inch 550 CFM Island Liner Insert

Available Now!

Vent A Hood SKU: TH248SLE BC

$2,603.00

Vent a Hood 48" 550 CFM Island Liner Insert
Vent a Hood 48" 550 CFM Island Liner Insert
Vent a Hood 48" 550 CFM Island Liner Insert
Vent a Hood 48" 550 CFM Island Liner Insert
Description Key Specifications Planning Notes Manufacturer Resources

The TH248SLE is a 48-inch island liner insert designed for a custom four-sided enclosure. Its T200 dual Magic Lung blower delivers 550 CFM rated airflow, while the 27-inch bottom depth provides capture coverage for standard cooking equipment.

  • Exact model: TH248SLE
  • Overall size: 48 inches wide x 27 inches deep x 12 inches high
  • Top dimensions: 36 inches wide x 15 inches deep
  • Airflow: 550 CFM; 900 CFM equivalent
  • Blower: T200 island dual Magic Lung
  • Electrical: 115 volts, 4.0 amps, 60 Hz
  • Minimum round duct size: 8 inches with included VP565 transition
  • Sound rating on high: 6.0 sones
  • Lighting: four LED lights, one at each corner
  • Recommended mounting height: 30 inches above the cooking surface
  • This liner is intended for a custom island enclosure and is not available with heat lamps.
  • Confirm enclosure dimensions, duct route and service access before ordering.
  • Confirm the final product selection and installation requirements with Vent-A-Hood or a qualified installer before ordering.
