Summit 19 Inch Outdoor ADA Beverage Center with Glass Door and Lock

• Built-in capable
  Make the best use of space by installing your refrigerator under the counter
• ADA compatible height
  Sized at 32.5" high for installation under most lower ADA compliant counters
• 17" shallow depth
  Ideal for home wet bars, island kitchens, and other applications with limited footprint space
• Weatherproof design
  Approved for use in the outdoors, with a sealed exterior and double pane tempered glass door
• Commercially approved
  ETL-S listed to NSF-7 standard and meets UL-471 for use in commercial settings
• Double pane tempered glass door
  Heat resistant design provides clear view of stored products, with an elegant trim in seamless stainless steel
• Automatic defrost
  Reduced user maintenance with auto defrost system
• Reversible door
  User-reversible door swing makes it easy to adjust to your setting as needed
• Factory installed lock
  Keyed lock offers added security, with two keys included
• Professional handle
  Stainless steel handle adds an attractive touch
• Adjustable shelves
  Three glass shelves with six positions for optimal storage and easy cleaning
• LED lighting
  Automatically illuminates when the door is open for an attractive and energy efficient view
• Black interior finish
  Allows for easy cleaning and organization within the interior of the unit

• Adjustable thermostat
  Dial thermostat with seven temperature settings offers easy temperature management
• Versatile construction
  Versatile design allows for residential use
• Sealed back
  Space saving design with easier cleanability and added protection from the elements
• Fully finished black cabinet
  Allows the unit to be used freestanding
• Right-angle plug
  Provides flexibility in unit placement without needing added depth
• 100% CFC free
  Environmentally friendly design does not contain ozone-damaging chemicals
• CARB Compliant
  Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations

• Capacity: 3.13 cu.ft. (89 L)
• Defrost Type: Automatic
• Door: Glass
• Cabinet: Black
• US Electrical Safety: ETL
• Canadian Electrical Safety: ETL-C
• Sanitation: ETL-S
• Energy Usage/Year: 285.0 kWh/year
• Amps: 1.3
• Voltage/Frequency: 115 V AC / 60 Hz
• Weight: 70.0 lbs. (32 kg)
• Parts & Labor Warranty: 1 Year
• Compressor Warranty: 5 Years
• Door Swing: RHD
• Reversible: Yes
• Shelf Type: Glass
• Shelf Qty: 3
• Adjustable Shelves: Yes
• Can Storage: Yes
• Thermostat Type: Dial
• Fan Type: Interior
• Refrigerant Type: R600a
• Refrigerant Amount: 0.88oz.
• High Side PSI: 320.0
• Low Side PSI: 120.0
• Level Legs Qty: 2
• Interior Light: Yes
• Temperature Range: 34 to 50ºF
• Sound Level: 32.6 dB

• Interior Height: 29 Inches
• Interior Width: 16 Inches
• Interior Depth: 12 3/4 Inches
• Compressor Step Height: 7 Inches
• Compressor Step Width: 16 Inches
• Compressor Step Depth: 6 1/4 Inches
