Vent-A-Hood TH466PSLE 66-Inch 1100 CFM Pro-Depth Island Liner Insert

Available Now!

Vent A Hood SKU: TH466PSLE BC

$4,439.00

Vent a Hood 66" 1100 CFM Island Liner Insert
Vent a Hood 66" 1100 CFM Island Liner Insert
Vent a Hood 66" 1100 CFM Island Liner Insert
Vent a Hood 66" 1100 CFM Island Liner Insert
Description Key Specifications Planning Notes Manufacturer Resources

The TH466PSLE is a 66-inch pro-depth island liner insert for a custom four-sided enclosure. Its high-capacity Magic Lung configuration delivers 1,100 CFM rated airflow, and the 30-inch bottom depth expands capture coverage for deeper cooking installations.

  • Exact model: TH466PSLE
  • Overall size: 66 inches wide x 30 inches deep x 12 inches high
  • Top dimensions: 50 inches wide x 22 inches deep
  • Airflow: 1,100 CFM; 1,800 CFM equivalent
  • Electrical: 115 volts
  • Minimum round duct size: 12 inches
  • Sound rating on high: 6.4 sones
  • Lighting: integrated LED lighting
  • Recommended mounting height: 30 inches above the cooking surface
  • This pro-depth liner is intended for a custom island enclosure and is not available with heat lamps.
  • Confirm enclosure dimensions, 12-inch duct route, electrical load and service access before ordering.
  • Confirm the final product selection and installation requirements with Vent-A-Hood or a qualified installer before ordering.
